Lenovo ThinkStation P720 - 1x Intel Xeon Silver 4208 - 1x 16GB RDIMM DDR4-2933 - Windows 10 Pro 64 for Workstations - 30BA00GFAX

1x Intel Xeon Silver 4208 (8C / 16T, 2.1 / 3.2GHz, 11MB)

2x FCLGA3647

None

Intel C621

1x 16GB RDIMM DDR4-2933 ECC

12 DIMM sockets with 12 channels. 6 DIMM sockets with 6 channels per processor

768GB (DDR4-2933 RDIMM) or 384GB (DDR4-2666 RDIMM)

RAID 0/1

None

Onboard Intel RSTe SATA

1x 1TB HDD 7200rpm 3.5" SATA6Gb/s

None

Up to 6x 3.5" SATA HDD / 10x 2.5" SATA HDD / 8x 2.5" SAS HDD / 10x 2.5" SATA SSD / 4x 2.5" PCIe SSD + 9x M.2 PCIe SSD + 2x PCIe AIC SSD • 3.5" HDD up to 4TB each • 2.5" SATA HDD up to 500GB each • 2.5" SAS HDD up to 600GB each • 2.5" SATA SSD up to 2TB each • M.2 SSD up to 2TB each • PCIe AIC SSD up to 480GB each

1x HH DVD±RW

High Definition (HD) Audio, Realtek ALC662 codec

1000W Platinum Fixed

USB Traditional Keyboard, Black, Arabic

USB Calliope Mouse

• One PCI
• Three PCIe 3.0 x16 (2nd CPU needed)
• One PCIe 3.0 x4
• One PCIe 3.0 x8

Up to 9x M.2 SSD: • 2 via onboard slots • 4 via Quad M.2 to PCIe adapter • 3 via Single M.2 to PCIe adapters

• 4x 3.5" disk bay (optional): 2 bays come with 3rd disk or Storage Bay Upgrade Kit 2 bays via Flex bay
• 2x 3.5" disk bay (standard)

2x flex bays. Supports the following: • 2x half-height optical drives • 2x 5.25" 9.0mm optical drives • 1x 5.25" 9.0mm optical drive + 2x 3.5"/2.5" SATA SSD/HDD • 1x 3.5"/2.5" SATA SSD/HDD with Front Access Storage Enclosure • 1x flex module for the following options: Tray 1: 9.0mm optical Tray 2: 15-in-1 USB 3.1 Gen 1 reader, 2x Thunderbolt, or 4-digit diagnostic display Port 1 and 2: Front USB 3.1 Gen 1 Type-C or eSATA • 2x M.2 SSD with 2x Front Removable Drive Enclosures

175 x 485 x 446 mm (6.89 x 19.1 x 17.6 inches, with feet)

25.7 kg (56.7 lbs, maximum configuration)

2x GbE RJ-45

None

None

SD Reader

• 1x headphone / microphone combo jack (3.5mm)
• 3x USB 3.1 Gen 1
• 1x USB 3.1 Gen 1 (Always On and fast charge)

None

• 1x line-in (3.5mm)
• 1x microphone (3.5mm)
• 2x Ethernet (RJ-45)
• 4x USB 3.1 Gen 1
• 2x PS/2 ports (keyboard/mouse)
• 1x line-out (3.5mm)
• 2x USB 2.0

1x Serial

• Access Panel Lock Kit with Unique Key
• Kensington Security Slot

Lock Kit with Unique Key

Chassis Intrusion Switch

Intel vPro with AMT 11, DASH

None

3-year, Onsite

3Y Premier Bundle MEA (CPN) (5WS1B05477)

• RoHS compliant
• EPEAT Silver
• ENERGY STAR 8.0 (On model 30BA00EQUS)
• GREENGUARD

Please visit www.thinkworkstations.com/isv-certifications/

Windows 10 Pro 64 for Workstations, Arabic / English

None
