Lenovo Think Station P520 PC - Intel Xeon W-2223 - 1x 16GB RDIMM DDR4 - Windows 10 Pro 64 for Workstations - 30BE00GKAX

Intel Xeon W-2223 (4C / 8T, 3.6 / 3.9GHz, 8.25MB)

1x FCLGA2066

None

Intel C422

1x 16GB RDIMM DDR4-2933 ECC

8 DIMM sockets with 4 channels

• Up to 512GB (with 8 x 64GB DDR4-2933 RDIMMs) on models with Intel Xeon W-2200 Series processor
• Up to 256GB (with 8 x 32GB DDR4-2666 RDIMMs) on models with Intel Xeon W-2100 Series processor

RAID 0/1

None

Onboard Intel RSTe SATA

1x 1TB HDD 7200rpm 3.5" SATA6Gb/s

None

Up to 6x 3.5" SATA HDD / 2.5" SATA HDD / 2.5" SATA SSD + 9x M.2 PCIe SSD + 1x PCIe AIC SSD • 3.5" HDD up to 6TB each • 2.5" SATA HDD up to 500GB each • 2.5" SATA SSD up to 2TB each • M.2 PCIe SSD up to 2TB each • PCIe AIC SSD up to 480GB each

1x HH DVD±RW

High Definition (HD) Audio, Realtek ALC662 codec

690W Platinum Fixed

USB Traditional Keyboard, Black, Arabic

USB Calliope Mouse

• Two PCIe 3.0 x4
• Two PCIe 3.0 x16
• One PCI
• One PCIe 3.0 x8

Up to 9x M.2 SSD: • 2 via onboard slots • 4 via Quad M.2 to PCIe adapter • 3 via Single M.2 to PCIe adapters

• 4x 3.5" disk bay (optional): 2 bays come with 3rd disk or Storage Bay Upgrade Kit 2 bays via Flex bay
• 2x 3.5" disk bay (standard)

2x flex bays. Supports the following: • 2x half-height optical drives • 2x 5.25" 9.0mm optical drives • 1x 5.25" 9.0mm optical drive + 2x 3.5"/2.5" SATA SSD/HDD • 1x 3.5"/2.5" SATA SSD/HDD with Front Access Storage Enclosure • 1x flex module for the following options: Tray 1: 9.0mm optical Tray 2: 15-in-1 USB 3.1 Gen 1 reader, 2x Thunderbolt, or 4-digit diagnostic display Port 1 and 2: Front USB 3.1 Gen 1 Type-C or eSATA • 2x M.2 SSD with 2x Front Removable Drive Enclosures

165 x 460 x 440 mm (6.5 x 18.1 x 17.3 inches, with feet)

24 kg (52.91 lbs, maximum configuration)

1x GbE RJ-45

None

None

SD Reader

• 3x USB 3.1 Gen 1
• 1x USB 3.1 Gen 1 (Always On and fast charge)
• 1x headphone / microphone combo jack (3.5mm)

None

• 1x line-in (3.5mm)
• 1x Ethernet (RJ-45)
• 1x microphone (3.5mm)
• 4x USB 3.1 Gen 1
• 2x PS/2 ports (keyboard/mouse)
• 1x line-out (3.5mm)
• 2x USB 2.0

1x Serial

Discrete TPM 1.2, TCG certified

• Access Panel Lock Kit with Unique Key
• Kensington Security Slot

Lock Kit with Unique Key

None

Intel vPro with AMT 11, DASH

None

3-year, Onsite

3Y Premier Bundle MEA (CPN) (5WS1B05477)

• RoHS compliant
• EPEAT Silver
• GREENGUARD
• ENERGY STAR 8.0 (On model 30BE00B7US)

Please visit www.thinkworkstations.com/isv-certifications/

Windows 10 Pro 64 for Workstations, Arabic / English

None
